Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-51
Possible settings: Code
Default Selection
Comment
Application control word bit 13: Reset cutting counter for test
operation.
TRUE Reset counter.
C4135/
000
Bit 13
0 0 {1} 1
FALSE Counter will not be reset.
Application control word bit 14: Start and stop selected cross-
cutter operating mode.
TRUE Start operation.
C4135/
000
Bit 14
0 0 {1} 1
FALSE Stop operation.
Application control word bit 15: Activate the bit to immediately
apply a new cutting length you have calculated and work with the
new cutting length.
TRUE Apply new cutting length calculated.
C4135/
000
Bit 15
0 0 {1} 1
FALSE Do not apply new cutting length calculated, continue
to work with the last cutting length calculated.
Application control word bit 16: Activate the bit to immediately
apply a new reject length you have calculated and work with the
new cutting length.
TRUE Apply new reject length calculated.
C4135/
000
Bit 16
0 0 {1} 1
FALSE Do not apply new reject length calculated, continue to
work with the last cutting length calculated.
Application control word bit 17: Activate the bit to immediately
apply a new test length you have calculated and work with the
new cutting length.
TRUE Apply new test length calculated.
C4135/
000
Bit 17
0 0 {1} 1
FALSE Do not apply new test length calculated, continue to
work with the last cutting length calculated.
Application control word 18: Activates X trimming and switches
from the calculated mark sensor distance to the mark sensor
distance specified by X trimming.
TRUE X trimming activated.
C4135/
000
Bit 18
0 0 {1} 1
FALSE X trimming deactivated.
Application control word bit 19: Key this input to perform X
trimming in a positive direction at the set speed.
TRUE Perform X trimming in a positive direction.
C4135/
000
Bit 19
0 0 {1} 1
FALSE Do not perform X trimming.
Application control word bit 20: Key this input to perform X
trimming in a negative direction at the set speed.
TRUE Perform X trimming in a negative direction.
C4135/
000
Bit 20
0 0 {1} 1
FALSE Do not perform X trimming.
Application control word bit 21: Activate print-mark
synchronisation.
TRUE Print-mark synchronisation enabled.
C4135/
000
Bit 21
0 0 {1} 1
FALSE Print-mark synchronisation disabled.
Application control word bit 22: Activate ramp generator for print-
mark synchronisation.
TRUE Ramp generator activated.
C4135/
000
Bit 22
0 0 {1} 1
FALSE Ramp generator deactivated.
Application control word bit 23: Reset of Counter for not detected
printmarks
TRUE Reset ofcounter for not detected printmarks
C4135/
000
Bit 23
0 0 {1} 1
FALSE No Reset of counter for not detected printmarks
