Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-55
Possible settings: Code
Default Selection
Comment
Application status word bit 16: Homing activated.
TRUE
Homing active.
C4150/
000
Bit 16
- - - -
FALSE Homing not active.
Application status word bit 17: Home position detected.
TRUE
Homing complete, home position detected.
C4150/
000
Bit 17
- - - -
FALSE Home position not detected (an encoder error
may have occurred).
Application status word bit 18: "Homing error" status signal.
TRUE
An error occurred when setting the home
position.
See g_nHomingErrorNo for more detailed
information about the error.
C4150/
000
Bit 18
- - - -
FALSE No errors occurred when setting the home
position.
Note!
Tip for assigning the PLC's digital input to the homing switch:
In the prepared solution, digital input 3 is designated as the homing switch.
The signals are wired in the CrossCutterInterfaces PRG (network 3).
Instead of the touch-probe signal via digital input (I4 using Servo PLC and I2 using ECS),
the zero pulse signal from the feedback system can also be used as the signal to determine
the home position.
