Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-6
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
g_wActNumberOfPointsTestProfile WORD Display indicating the most recently calculated interpolation point on the motion
profile selected via g_wActCamTestProfileNoCalc; this output can be used as a
progress indicator, for example.
The value range is 0 … (g_wTotalNumberOfPointsTestProfile - 1).
g_wActNumberOfPointsStartStopProfile
WORD Display indicating the most recently calculated interpolation point on the motion
profile selected via g_wActCamStartStopProfileNoCalc; this output can be used as
a progress indicator, for example.
The value range is 0 … (g_wTotalNumberOfPointsStartStopProfile - 1).
g_wActNumberOfPointsAsyCuttingProfile
WORD Display indicating the most recently calculated interpolation point on the motion
profile for the asynchronus cutting, this output can be used as a progress indicator,
for example.
The value range is 0 … (g_wTotalNumberOfPointsAsyCuttingProfile - 1).
Status signal: Calculation sequence for new cross-cutter motion profile for a new
cutting length in progress.
TRUE
Calculation sequence for cross-cutter
motion profile for a new cutting length in
progress.
g_bCrossCutterCalcBusyCuttingProfile
BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new cutting
length completed successfully or
aborted.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
reject length in progress.
TRUE
Calculation sequence for cross-cutter
motion profile for a new reject length in
progress.
g_bCrossCutterCalcBusyRejectProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new reject
length completed successfully or
aborted.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
test length in progress.
TRUE
Calculation sequence for cross-cutter
motion profile for a new test length in
progress.
g_bCrossCutterCalcBusyTestProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new test length
completed successfully or aborted.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
start/stop length in progress.
TRUE
Calculation sequence for cross-cutter
motion profile for a new start/stop length
in progress.
g_bCrossCutterCalcBusyStartStopProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new start/stop
length completed successfully or
aborted.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
asynchronus length in progress.
TRUE
Calculation sequence for cross-cutter
motion profile for a new asynchronus
length in progress.
g_bCrossCutterCalcBusyAsyCuttingProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new
asynchronus length completed
successfully or aborted.
