Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-71
Possible settings: Code
Default Selection
Comment
C3669/
000
60.0000 0.0000... {0.0001
m_units}
... 214000.0000
Size of mark window
C3670/
000
1 0 ... {1} ... 65535 Number of cycles permitted without a mark signal appearing in
the mark window. A warning signal is generated if this number is
exceeded.
Application status word bit 26: This status signal indicates that the
maximum number of cycles completed without a mark signal
appearing in the mark window has been exceeded.
TRUE
The maximum number of cycles without a mark
signal appearing in the mark window has been
reached.
C4150/
000
Bit 26
- - - -
FALSE The maximum number of cycles without a mark
signal appearing in the mark window has not been
reached.
The warning signals listed in the table below may occur during monitoring of the mark window.
Each warning signal will remain pending until the next print-mark signal appears in the mark
window. Warning signals can also be displayed via bit 26 of the application status word
(C4150/000).
Each warning signal is generated in the specified network of the UserErrors block (POU).
Warning signals
Number Text Global variable Network in
UserErrors
POU
507 MaxNumberOfTPOutOfWin g_bMaxNumberOfTPOutOfWindowIncreased 8
Note!
Digital input 5 on the Servo PLC or I1 on the ECS is permanently assigned to the print-
mark-sensor signal. The user needs to assign the print-mark-sensor signal to this input!
