Lenze EVS93xx CrossCutter - Manual (Page 209)

Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-41
Possible settings: Code
Default Selection
Comment
Positioning mode
0
Move to target position via shortest route.
1 Move to target position only in positive
direction (CW).
2 Move to target position only in negative
direction (CCW).
C3629/
000
0 0 {1} 4
4 Positioning relative to entry in C3628/000
(g_dnToolPositionSet).
Positioning mode Lock to cam
0
Move to cam position via shortest route.
1 Move to cam position only in positive
direction (CW).
C3630/
000
0 0 {1} 2
2 Move to cam position only in negative
direction (CCW).
Inversion of DFIN signal
TRUE
Invert DFIN signal.
C3635/
000
0 0 {1} 1
FALSE Do not invert DFIN signal.
Motor mounting direction
TRUE
Motor mounting direction inverted.
C3636/
000
0 0 {1} 1
FALSE Motor mounting direction not inverted.
C3637/
000
1 -32767 {1} ... 32767 Gearbox (numerator) position feedback
It is not allowed to set the value Zero!
C3638/
000
1 1... {1} ... 32767
Gearbox (denominator) position feedback
C3639/
000
1 -200... {1 %} ... 200
external torque precontrol
Function of external torque precontrol
0
TorqueOut = TorqueIn1
1 TorqueOut = TorqueIn1 + TorqueIn2
2 TorqueOut = TorqueIn1 − TorqueIn2
3
TorqueOut =
16384
2 1 TorqueIn TorqueIn
⋅
4
TorqueOut =
164
2
1 ⋅
TorqueIn
TorqueIn
C3640/
000
1 0 {1} 5
5
TorqueOut =
16384
2 16384
1
⋅
−TorqueIn
TorqueIn
C3643 3.0000 0.0001... {0.0001
[s_units]}
... 214748.0000 Selection of following error switch-off threshold
C3644 0.5000 0.0001... {0.0001
[s_units]}
... 214748.0000 Selection of following error hysteresis
C3645 1.5000 0.0001... {0.0001
[s_units]}
... 214748.0000 Selection of following error warning limit
C3646 0.5000 0.0001... {0.0001
[s_units]}
... 214748.0000 Selection of following error warning limit hysteresis
C3649/
001
0.100 0.000... {0.01[s]} ...129.99 Abort ramp for ramp generator: Assumes a speed of 4000 rpm.
Used if the knife cuts into the material whilst mark correction is in
progress.
C3649/
002
5.000 0.000... {0.01[s]} ...129.99 Acceleration ramp for ramp generator: Assumes a speed of 4000
rpm.
C3649/
003
5.000 0.000... {0.01[s]} ...129.99 Deceleration ramp for ramp generator: Assumes a speed of 4000
rpm.
C3650/
001
200 0 {1 rpm} 15000 Maximum positive correction speed for mark synchronisation with
a ramp generator and correction speed for mark synchronisation
without a ramp generator.
C3650/
002
200 {1 rpm} 15000 Maximum negative correction speed for mark synchronisation
with a ramp generator.
C3653/
000
628.3185 0.0000... {0.0001
m_units}
... 214748.0000
Cutting circle circumference of knife drum
