Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-42
Possible settings: Code
Default Selection
Comment
C3654/
000
30.0000 0.0000... {0.0001
s_units}
... 360.0000
Cutting angle (synchronous angle)
C3655/
000
300.0000 0.0001... {0.0001
m_units}
... 214000.0000 Setpoint cutting length (valid for synchronous and asynchronous
cross-cutter operation).
C3656/
000
150.0000 0.0001... {0.0001
m_units}
... 214000.0000
Setpoint for reject length
C3657/
000
2400.0000 0.0001... {0.0001
m_units}
... 214000.0000
Setpoint for test length
C3658/
000
- - {1} - Display code: Cutting counter for cutting operation
The counter is limited to a maximum value of 65535; on reaching
this value it will overflow to 0.
C3659/
000
- - {1} - Display code: Cutting counter for reject operation
The counter is limited to a maximum value of 65535; on reaching
this value it will overflow to 0.
C3660/
000
- - {1} - Display code: Cutting counter for test operation
The counter is limited to a maximum value of 65535; on reaching
this value it will overflow to 0.
Display code: Status of calculation sequence for new cutting
length
0 Calculation ok.
1 • No LC9 file found.
• Profile data not found in absolute data model.
• Read error when accessing profile data.
2 Selected motion profile not found.
4 The angle of motion of the knife drum for the
asynchronous motion phase is less than or equal to zero
(check y final value of basic profile and cutting angle!).
8 A value of zero has been entered for the knife drum's
cutting circle circumference.
6 The preset cutting length is less than the material length
corresponding to the cutting angle.
32 The selected motion profile contains fewer than 20
interpolation points.
64 The selected motion profile does not start at zero
(0.0000/0.0000).
128 Cutting angle too small.
256 The y final value of the basic profile does not correspond
to value 360.0000[°]/n
cuts/rev
.
(n
cuts/rev
= Number of knives on knife drum, values of 1, 2,
3, 4, 5 or 6 are possible)
512 Error during internal read access to C0011/000
C3661/
000
- - {1} -
If the status variable is exhibiting non-zero values, the calculated
variables may exhibit invalid values, in which case it will not be
possible to use them subsequently in the control program!
