1.5 Conventions used
This Manual uses the following conventions to distinguish between the different types of
information:
Type of information Representation Example
Names of dialog boxes, input
fields and selection lists italic The Options dialog box
Names of identifiers (names of
variables) and program
organisation units (POUs =
functions, function blocks,
programs) italic Setpoint generation for the drive takes place in the MotionControl section of the
program.
Buttons bold Click OK to...
You can use the Messages command to... Menu commands bold
If several commands need to be carried out in succession in order to execute a
function, the individual commands will be separated by an arrow:
Select File Open to...
Press to open the input assistance. Keyboard commands bold
A "+" will appear in between commands to indicate that a command requires a key
combination:
Press + to...
Program listing Courier IF var1 < var2 THEN...
Key words Courier bold ...starts with FUNCTION and ends with END FUNCTION.
Important note Caution!
Do not use the Online Controller inhibit command for an emergency stop via
the PC as this command is sent to the controller subject to a delay.
Tip TIP!
Hover the mouse pointer over a symbol on the toolbar to display a tooltip indicating
the corresponding command.
Variable names
The conventions used by Lenze for the variable names of its system blocks, function blocks and
functions are based on what is known as "Hungarian Notation". This allows you to identify the
most important properties (e.g. the data type) of a variable immediately by means of its name,
e.g. DIGIN_bIn1_b.
You will find information about the conventions in the appendix of the DDS Online
documentation "Introduction to IEC1131-3 programming”.
