Cross Cutter
Preface and general information
Prepared Solution Servo PLC / ECSxA 1.1 EN 1-3
*.CMM
CrossCutter_Vxxxxxx.cmm
Project sample files for CamManager/CamDesigner Professional:
A sample project for CamDesigner Professional has been included to
illustrate a sample application. The project comprises a CMM file and the
following associated CAM files:
Product1_Prof.cam
Product2_Prof.cam
Product3_Prof.cam
Product4_Prof.cam
Product5_Prof.cam
Product6_Prof.cam
Product7_Prof.cam
Product8_Prof.cam
Product9_Prof.cam
Product10_Prof.cam
The compiled sample cam file for the cross-cutter axis is called:
CrossCutterProf.lc9
*.Cam
CrossCutter_Vxxxxxx.cmm
Project sample files for CamDesigner Basic:
A sample project for CamDesigner Basic has been included to illustrate a
sample application. The project comprises a CMM file and the following
associated CAM files:
Product1_Basic.cam
Product2_Basic.cam
Product3_Basic.cam
Product4_Basic.cam
Product5_Basic.cam
Product6_Basic.cam
Product7_Basic.cam
Product8_Basic.cam
Product9_Basic.cam
Product10_Basic.cam
The compiled sample cam file for the cross-cutter axis is called:
CrossCutterBasic.lc9
*.PDF
CrossCutter_vx-x_DE.pdf
PDF file (manual) German:
The PDF file contains the manual to accompany the prepared solution
(documentation) in German.
CrossCutter_vx-x_EN.pdf PDF file (manual) English:
The PDF file contains the manual to accompany the prepared solution
(documentation) in English.
The files are installed using an installation wizard.
Users will need to generate additional project files for the "Cross Cutter" prepared solution
(these include a file containing profile data for cross-cutter applications). A description of how to
generate these files appears in Chapter 3.4.2.
Caution!
The cam files supplied (CMM, CAM and LC9 files) serve simply as a sample project for
creating application-specific profile data and must not be used in the context of actual systems.
