Prepared Solution Servo PLC / ECSxA 1.1 EN 6-52
Possible settings: Code
Default Selection
Comment
Application control word bit 24: Abort cross cutter operation
TRUE Abort cross cutter operation
C4135/
000
Bit 24
0 0 {1} 1
FALSE No abort of cross cutter operation
Application control word bit 25: Enable X-trimming positioning
TRUE Enable X-trimming positioning
C4135/
000
Bit 25
0 0 {1} 1
FALSE Disable X-trimming positioning
Application control word bit 26: Not assigned
TRUE -
C4135/
000
Bit 26
0 0 {1} 1
FALSE -
Application control word bit 27: Not assigned
TRUE -
C4135/
000
Bit 27
0 0 {1} 1
FALSE -
Application control word bit 28: Not assigned
TRUE -
C4135/
000
Bit 28
0 0 {1} 1
FALSE -
Application control word bit 29: Not assigned
TRUE -
C4135/
000
Bit 29
0 0 {1} 1
FALSE -
Application control word bit 30: Not assigned
TRUE -
C4135/
000
Bit 30
0 0 {1} 1
FALSE -
Application control word bit 31: Not assigned
TRUE -
C4135/
000
Bit 31
0 0 {1} 1
FALSE -
C4136/
000
- - - - Display code: Current application control word
Control word: Selection of operating mode for the cross cutter
Note: You can switch between modes 1 to 3 during operation. To
switch to mode 4 from one of modes 1 to 3, you will first need to
stop the cross cutter via C4135 bit 14 (g_bStartStopOperation).
To switch from mode 4 to one of modes 1 to 3, you will first need
to stop the cross cutter via C4135 bit 14 (g_bStartStopOperation).
1 Synchronous cross cutter, continuous cutting
2 Synchronous cross cutter, reject operation
3 Synchronous cross cutter, test operation
C4137/
000
0 1 {1} 4
4 Asynchronous cross cutter, continuous cutting
Display code: Current value of control word. (Selection of
operating mode for cross cutter.)
1 Synchronous cross cutter, continuous cutting
2
Synchronous cross cutter, reject operation
3 Synchronous cross cutter, test operation
C4138/
000
0 - {1} -
4 Asynchronous cross cutter, continuous cutting
