Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-40
Possible settings: Code
Default Selection
Comment
Application status word bit 11: Calculation sequence for new
cross-cutter motion profile for a new start/stop length in progress.
TRUE Calculation sequence for cross-cutter motion profile
for a new start/stop length in progress.
C4150/
000
Bit 11
- - - -
FALSE Calculation sequence for new cross-cutter motion
profile for a new start/stop length completed
successfully or aborted.
Application status word bit 12: Calculation sequence for new
cross-cutter motion profile for a new cutting length completed
successfully.
Starting a new calculation sequence will reset this bit to FALSE.
TRUE
Calculation sequence for new cross-cutter motion
profile for a new cutting length completed
successfully.
C4150/
000
Bit 12
- - - -
FALSE Calculation sequence for new cross-cutter motion
profile for a new cutting length not completed.
Application status word bit 13: Calculation sequence for new
cross-cutter motion profile for a new reject length completed
successfully.
Starting a new calculation sequence will reset this bit to FALSE.
TRUE
Calculation sequence for new cross-cutter motion
profile for a new reject length completed successfully.
C4150/
000
Bit 13
- - - -
FALSE Calculation sequence for new cross-cutter motion
profile for a new reject length not completed.
Application status word bit 14: Calculation sequence for new
cross-cutter motion profile for a new test length completed
successfully.
Starting a new calculation sequence will reset this bit to FALSE.
TRUE
Calculation sequence for new cross-cutter motion
profile for a new test length completed successfully.
C4150/
000
Bit 14
- - - -
FALSE Calculation sequence for new cross-cutter motion
profile for a new test length not completed.
Application status word bit 15: Calculation sequence for new
cross-cutter motion profile for a new start/stop length completed
successfully.
Starting a new calculation sequence will reset this bit to FALSE.
TRUE
Calculation sequence for new cross-cutter motion
profile for a new start/stop length completed
successfully.
C4150/
000
Bit 15
- - - -
FALSE Calculation sequence for new cross-cutter motion
profile for a new start/stop length not completed.
