Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-41
Possible settings: Code
Default Selection
Comment
Application status word bit 20: The cross cutter is operating as an
asynchronous cross cutter.
TRUE
The cross cutter is operating as an asynchronous
cross cutter.
C4150/
000
Bit 20
- - - -
FALSE The cross cutter is not operating as an asynchronous
cross cutter.
Application status word bit 21: The cross cutter is operating as a
synchronous cross cutter.
TRUE The cross cutter is operating as a synchronous cross
cutter.
C4150/
000
Bit 21
- - - -
FALSE The cross cutter is not operating as a synchronous
cross cutter.
Application status word bit 22: The cross cutter is operating in
"Continuous cutting" mode.
TRUE The cross cutter is operating in "Continuous cutting"
mode.
C4150/
000
Bit 22
- - - -
FALSE The cross cutter is not operating in "Continuous
cutting" mode.
Application status word bit 23: The cross cutter is operating in
"Reject operation" mode.
TRUE The cross cutter is operating in "Reject operation"
mode.
C4150/
000
Bit 23
- - - -
FALSE The cross cutter is not operating in "Reject operation"
mode.
Application status word bit 24: The cross cutter is operating in
"Test operation" mode.
TRUE
The cross cutter is operating in "Test operation"
mode.
C4150/
000
Bit 24
- - - -
FALSE The cross cutter is not operating in "Test operation"
mode.
Application status word 31: All calculation sequences for new
cross-cutter motion profiles have been completed successfully.
Starting a new calculation sequence will reset this status output to
FALSE.
TRUE
All calculation sequences for new cross-cutter motion
profiles have been completed successfully.
C4150/
000
Bit 31
- - - -
FALSE All calculation sequences for new cross-cutter motion
profiles are still in progress.
The warning signals listed in the following table may appear when calculating cross-cutter
motion profiles. Each warning signal will remain pending until its cause has been dealt with.
Each warning signal is generated in the specified network of the UserErrors block (POU).
Warning signals
Number Text Global variable Network in
UserErrors
POU
501 WrongProfileForCalc g_bWrongSetCamProfileNoForCalc 2
503 ErrorCalcCuttingProfile g_bErrorCrossCutterCuttingProfileCalcBlock 4
504 ErrorCalcRejectProfile g_bErrorCrossCutterRejectProfileCalcBlock 5
505 ErrorCalcTestProfile g_bErrorCrossCutterTestProfileCalcBlock 6
506 ErrorCalcStartStopProfile g_bErrorCrossCutterStartStopProfileCalcBlock 7
