Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-17
Inputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
g_wRejectProfileStandby WORD Selection of motion profile 4 as standby motion profile for reject operation.
If the reject length changes, the system will switch between the main and standby
motion profiles.
g_wTestProfileMain WORD Selection of motion profile 5 as main motion profile for test operation.
If the test length changes, the system will switch between the main and standby
motion profiles.
g_wTestProfileStandby WORD Selection of motion profile 6 as standby motion profile for test operation.
If the test length changes, the system will switch between the main and standby
motion profiles.
g_wStartStopProfileMain WORD Selection of motion profile 7 as main motion profile for start/stop operation.
If the start/stop length changes, the system will switch between the main and
standby motion profiles.
g_wStartStopProfileStandby WORD Selection of motion profile 8 as standby motion profile for start/stop operation.
If the start/stop length changes, the system will switch between the main and
standby motion profiles.
Status signal: This signal indicates that the current position value of the master
value axis is equivalent to or in excess of the start/stop position
(g_dnX1CalcStartStopProfile_p ) of the cross cutter.
TRUE
Start/stop position reached.
g_bStopDFIN BOOL
FALSE Start/stop position not reached.
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Status signal: The cross cutter is operating as a synchronous cross cutter.
TRUE
The cross cutter is operating as a
synchronous cross cutter.
g_bUseSynchronusCrossCutter BOOL
FALSE The cross cutter is not operating as a
synchronous cross cutter.
Status signal: The cross cutter is operating as an asynchronous cross cutter.
TRUE
The cross cutter is operating as an
asynchronous cross cutter.
g_bUseAsynchronusCrossCutter BOOL
FALSE The cross cutter is not operating as an
asynchronous cross cutter.
Status signal: The cross cutter is operating in "Continuous cutting" mode.
TRUE
The cross cutter is operating in
"Continuous cutting" mode.
g_bUseCuttingProfile BOOL
FALSE The cross cutter is not operating in
"Continuous cutting" mode.
Status signal: The cross cutter is operating in "Reject operation" mode.
TRUE
The cross cutter is operating in "Reject
operation" mode.
g_bUseRejectProfile BOOL
FALSE The cross cutter is not operating in
"Reject operation" mode.
