Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-83
Variable name
Inputs (Variable type: VAR_INPUT)
Name Data type Meaning
Selection of the target interface for the application's status information:
0 Status code
1 CAN1
2 CAN2
3 CAN3
4 AIF1
5 AIF2
byOutputSource BYTE
6 AIF3
wDCTRL_wStat WORD Input for the system status word (system variable DCTRL_wStat)
wStatW1_a INT Free entry of the first data word (this value is then output at the wInternalStatW1_a,
wCAN1_nOutW1_a, wCAN2_nOutW2_a, wCAN3_nOutW2_a, wAIF1_nOutW1_a, wAIF2_nOutW2_a
or wAIF3_nOutW2_a variable in accordance with the value at byOutputSource)
bBit00
bBit01
bBit02
bBit03
…
bBit30
bBit31
BOOL Bit-by-bit entry of status information (bits 0 to 31):
The internal status double word dwStatWord is generated from the individual bits. Each input bit
bBit00, bBit01 … bBit31 can be assigned to any bit in the status double word (dwStatWord.0 …
dwStatWord.31). The internal index variable abyStatWord[i] (i = 0 … 31) is used for assignment,
whereby the index i addresses the required bit in the status double word (dwStatWord.0 …
dwStatWord.31) and the value of abyStatWord[i] defines the required input bit (bBit00, bBit01 …
bBit31) for this output bit. The permissible value range for abyStatWord[i] is 0 … 31.
Outputs (Variable type: VAR_OUTPUT)
Name Data type Meaning
wCAN1_wDctrlStat WORD Output for system variable CAN1_wDctrlStat
wCAN1_nOutW1_a WORD Output for system variable CAN1_nOutW1_a
wCAN1_nOutW2_a WORD Output for system variable CAN1_nOutW2_a
wCAN1_nOutW3_a WORD Output for system variable CAN1_nOutW3_a
wCAN2_nOutW1_a WORD Output for system variable CAN2_nOutW1_a
wCAN2_nOutW2_a WORD Output for system variable CAN2_nOutW2_a
wCAN2_nOutW3_a WORD Output for system variable CAN2_nOutW3_a
wCAN2_nOutW4_a WORD Output for system variable CAN2_nOutW4_a
wCAN3_nOutW1_a WORD Output for system variable CAN3_nOutW1_a
wCAN3_nOutW2_a WORD Output for system variable CAN3_nOutW2_a
wCAN3_nOutW3_a WORD Output for system variable CAN3_nOutW3_a
wCAN3_nOutW4_a WORD Output for system variable CAN3_nOutW4_a
wAIF1_wDctrlStat WORD Output for system variable AIF1_wDctrlStat
wAIF1_nOutW1_a WORD Output for system variable AIF1_nOutW1_a
wAIF1_nOutW2_a WORD Output for system variable AIF1_nOutW2_a
wAIF1_nOutW3_a WORD Output for system variable AIF1_nOutW3_a
wAIF2_nOutW1_a WORD Output for system variable AIF2_nOutW1_a
wAIF2_nOutW2_a WORD Output for system variable AIF2_nOutW2_a
wAIF2_nOutW3_a WORD Output for system variable AIF2_nOutW3_a
wAIF2_nOutW4_a WORD Output for system variable AIF2_nOutW4_a
wAIF3_nOutW1_a WORD Output for system variable AIF3_nOutW1_a
wAIF3_nOutW2_a WORD Output for system variable AIF3_nOutW2_a
wAIF3_nOutW3_a WORD Output for system variable AIF3_nOutW3_a
