Prepared Solution Servo PLC / ECSxA 1.1 EN 6-80
Variable name
Inputs (Variable type: VAR_INPUT)
Name Data type Meaning
Selection of control source for application:
0 Control code
1 CAN1
2 CAN2
3 CAN3
4 AIF1
5 AIF2
byInputSource BYTE
6 AIF3
wCAN1_wDctrlCtrl WORD Input for system variable CAN1_wDctrlCtrl
wCAN1_nInW1_a WORD Input for system variable CAN1_nInW1_a
wCAN1_nInW2_a WORD Input for system variable CAN1_nInW2_a
wCAN1_nInW3_a WORD Input for system variable CAN1_nInW3_a
wCAN2_nInW1_a WORD Input for system variable CAN2_nInW1_a
wCAN2_nInW2_a WORD Input for system variable CAN2_nInW2_a
wCAN2_nInW3_a WORD Input for system variable CAN2_nInW3_a
wCAN2_nInW4_a WORD Input for system variable CAN2_nInW4_a
wCAN3_nInW1_a WORD Input for system variable CAN3_nInW1_a
wCAN3_nInW2_a WORD Input for system variable CAN3_nInW2_a
wCAN3_nInW3_a WORD Input for system variable CAN3_nInW3_a
wCAN3_nInW4_a WORD Input for system variable CAN3_nInW4_a
wAIF1_wDctrlCtrl WORD Input for system variable AIF1_wDctrlCtrl
wAIF1_nInW1_a WORD Input for system variable AIF1_nInW1_a
wAIF1_nInW2_a WORD Input for system variable AIF1_nInW2_a
wAIF1_nInW3_a WORD Input for system variable AIF1_nInW3_a
wAIF2_nInW1_a WORD Input for system variable AIF2_nInW1_a
wAIF2_nInW2_a WORD Input for system variable AIF2_nInW2_a
wAIF2_nInW3_a WORD Input for system variable AIF2_nInW3_a
wAIF2_nInW4_a WORD Input for system variable AIF2_nInW4_a
wAIF3_nInW1_a WORD Input for system variable AIF3_nInW1_a
wAIF3_nInW2_a WORD Input for system variable AIF3_nInW2_a
wAIF3_nInW3_a WORD Input for system variable AIF3_nInW3_a
wAIF3_nInW4_a WORD Input for system variable AIF3_nInW4_a
Outputs (Variable type: VAR_OUTPUT)
Name Data type Meaning
wDCTRL_wCAN1Ctrl WORD Output of control word for system variable DCTRL_wCAN1Ctrl
wDCTRL_wAIF1Ctrl WORD Output of control word for system variable DCTRL_wAIF1Ctrl
wCtrlW1_a INT Output of the first data word (derived from the wInternalCtrlW1_a, wCAN1_nInW1_a,
wCAN2_nInW2_a, wCAN3_nInW2_a, wAIF1_nInW1_a, wAIF2_nInW2_a or wAIF3_nInW2_a variable
in accordance with the value at byInputSource)
