Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN
2-39
Possible settings:
Code
Default
Selection
Comment
Application control word bit 16: Activate to immediately apply a
new reject length you have calculated and work with the new
cutting length.
TRUE
Apply new reject length calculated.
C4135/
000
Bit 16
0 0
{1}
1
FALSE
Do not apply new reject length calculated, continue to
work with the last cutting length calculated.
Application control word bit 17: Activate to immediately apply a
new test length you have calculated and work with the new
cutting length.
TRUE
Apply new test length calculated.
C4135/
000
Bit 17
0 0
{1}
1
FALSE
Do not apply new test length calculated, continue to
work with the last cutting length calculated.
Select cross-cutter operating mode.
Note: You can switch between modes 1 to 3 during operation. To
switch to mode 4 from one of modes 1 to 3, you will first need to
stop the cross cutter via g_bStartStopOperation. To switch from
mode 4 to one of modes 1 to 3, you will first need to stop the
cross cutter via g_bStartStopOperation.
1
Synchronous cross cutter, continuous cutting
2
Synchronous cross cutter, reject operation
3
Synchronous cross cutter, test operation
C4137/
000
1 1
{1}
4
4
Asynchronous cross cutter, continuous cutting
Application status word bit 8: Calculation sequence for new cross-
cutter motion profile for a new cutting length in progress.
TRUE
Calculation sequence for cross-cutter motion profile
for a new cutting length in progress.
C4150/
000
Bit 8
- -
-
-
FALSE
Calculation sequence for new cross-cutter motion
profile for a new cutting length completed
successfully or aborted.
Application status word bit 9: Calculation sequence for new cross-
cutter motion profile for a new reject length in progress.
TRUE
Calculation sequence for cross-cutter motion profile
for a new reject length in progress.
C4150/
000
Bit 9
- -
-
-
FALSE
Calculation sequence for new cross-cutter motion
profile for a new reject length completed successfully
or aborted.
Application status word bit 10: Calculation sequence for new
cross-cutter motion profile for a new test length in progress.
TRUE
Calculation sequence for cross-cutter motion profile
for a new test length in progress.
C4150/
000
Bit 10
- -
-
-
FALSE
Calculation sequence for new cross-cutter motion
profile for a new test length completed successfully or
aborted.
