Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-34
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Status signal: An error occurred whilst calculating the motion profile for the new
reject length.
TRUE
An error has occurred during calculation.
g_bErrorCrossCutterRejectProfileCalcBlock BOOL
FALSE Calculation completed without errors.
Status signal: An error occurred whilst calculating the motion profile for the new test
length.
TRUE
An error has occurred during calculation.
g_bErrorCrossCutterTestProfileCalcBlock BOOL
FALSE Calculation completed without errors.
Status signal: An error occurred whilst calculating the motion profile for the new
start/stop length.
TRUE
An error has occurred during calculation.
g_bErrorCrossCutterStartStopProfileCalc
Block BOOL
FALSE Calculation completed without errors.
Status signal: The cross cutter is operating as a synchronous cross cutter.
This value is displayed in code C4150/000 bit 21.
TRUE
The cross cutter is operating as a
synchronous cross cutter.
g_bUseSynchronusCrossCutter BOOL
FALSE The cross cutter is not operating as a
synchronous cross cutter.
Status signal: The cross cutter is operating as an asynchronous cross cutter.
This value is displayed in code C4150/000 bit 20.
TRUE
The cross cutter is operating as an
asynchronous cross cutter.
g_bUseAsynchronusCrossCutter BOOL
FALSE The cross cutter is not operating as an
asynchronous cross cutter.
Status signal: The cross cutter is operating in "Continuous cutting" mode.
This value is displayed in code C4150/000 bit 22.
TRUE
The cross cutter is operating in
"Continuous cutting" mode.
g_bUseCuttingProfile BOOL
FALSE The cross cutter is not operating in
"Continuous cutting" mode.
Status signal: The cross cutter is operating in "Reject operation" mode.
This value is displayed in code C4150/000 bit 23.
TRUE
The cross cutter is operating in "Reject
operation" mode.
g_bUseRejectProfile BOOL
FALSE The cross cutter is not operating in
"Reject operation" mode.
Status signal: The cross cutter is operating in "Test operation" mode.
This value is displayed in code C4150/000 bit 24.
TRUE
The cross cutter is operating in "Test
operation" mode.
g_bUseTestProfile BOOL
FALSE The cross cutter is not operating in "Test
operation" mode.
g_nMaxMasterVelForActCuttingProfile_v INT Entry indicating the maximum possible line speed for the set cutting length in
[incr./ms].
g_nMaxMasterVelForActRejectProfile_v INT Entry indicating the maximum possible line speed for the set reject length in
[incr./ms].
g_nMaxMasterVelForActTestProfile_v INT Entry indicating the maximum possible line speed for the set test length in [incr./ms].
g_nMaxMasterVelForActStartStopProfile_v INT Entry indicating the maximum possible line speed for the set start/stop length in
[incr./ms].
g_wCounterValueCuttingProfile WORD Cutting counter for cutting operation
The counter is limited to a maximum value of 65535; on reaching this value it will
overflow to 0. This value is displayed in code C3658/000.
g_wCounterValueRejectProfile WORD Cutting counter for reject operation
The counter is limited to a maximum value of 65535; on reaching this value it will
overflow to 0. This value is displayed in code C3659/000.
