Lenze EVS93xx CrossCutter - Manual (Page 223)

Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-55
Possible settings: Code
Default Selection
Comment
Application status word bit 18: Homing error
TRUE
An error occurred when setting the home position.
See g_nHomingErrorNo for more detailed information
about the error.
C4150/
000
Bit 18
- - - -
FALSE No errors occurred when setting the home position.
Application status word bit 19: Not assigned
TRUE -
C4150/
000
Bit 19
- - - -
FALSE -
Application status word bit 20: The cross cutter is operating as an
asynchronous cross cutter.
TRUE
The cross cutter is operating as an asynchronous
cross cutter.
C4150/
000
Bit 20
- - - -
FALSE The cross cutter is not operating as an asynchronous
cross cutter.
Application status word bit 21: The cross cutter is operating as a
synchronous cross cutter.
TRUE The cross cutter is operating as a synchronous cross
cutter.
C4150/
000
Bit 21
- - - -
FALSE The cross cutter is not operating as a synchronous
cross cutter.
Application status word bit 22: The cross cutter is operating in
"Continuous cutting" mode.
TRUE The cross cutter is operating in "Continuous cutting"
mode.
C4150/
000
Bit 22
- - - -
FALSE The cross cutter is not operating in "Continuous
cutting" mode.
Application status word bit 23: The cross cutter is operating in
"Reject operation" mode.
TRUE The cross cutter is operating in "Reject operation"
mode.
C4150/
000
Bit 23
- - - -
FALSE The cross cutter is not operating in "Reject operation"
mode.
Application status word bit 24: The cross cutter is operating in
"Test operation" mode.
TRUE
The cross cutter is operating in "Test operation"
mode.
C4150/
000
Bit 24
- - - -
FALSE The cross cutter is not operating in "Test operation"
mode.
Application status word bit 25: Opening reject gate.
TRUE Open the reject gate.
C4150/
000
Bit 25
- - - -
FALSE Do not open the reject gate.
Application status word bit 26: The maximum number of cycles
without a mark signal appearing in the mark window has been
exceeded.
TRUE
The maximum number of cycles without a mark
signal appearing in the mark window has been
reached.
C4150/
000
Bit 26
- - - -
FALSE The maximum number of cycles without a mark
signal appearing in the mark window has not been
reached.
Application status word bit 27: System enabling print-mark
control.
TRUE Print-mark control enabled by the system.
C4150/
000
Bit 27
- - - -
FALSE Print-mark control not enabled by the system.
