Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-12
3. Mark-controlled operation, with print-mark suppression: In this operating mode,
the cross cutter works with mark control and higher-level length control. A mark is
made on the material wherever a cut needs to be made. Other marks which have to be
ignored by the system appear before and after the print mark relevant for the cut. In
this operating mode, the cross cutter can be changed over when idle. However, it
cannot be changed over from operating status to idle state!
4. Mark-controlled operation, with multiple cuts (divisions) between two print
marks: In this operating mode the print-mark distance between print marks is a
multiple of the required cutting length. The cross cutter works with mark control and
higher-level length control. In this operating mode, the cross cutter can be changed
over when idle and during operation.
5. Mark-controlled operation, with multiple cuts between two print marks and
print-mark suppression: In this operating mode the print-mark distance is a
multiple of the required cutting length. Other marks which have to be ignored
also appear in between the relevant print marks. The prepared solution does not
support this type of operation!
