Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-17
2.5 Basic features
2.5.1 Reposition unlocked drive to motion profile
The Prepared Solution 'Cross Cutter' offers different ways to reposition on the motion profile. Regarding this,
three different modes are made available to the user. The tool can either be repositioned on the motion
profile on the shortest way possible, in clockwise (cw) or counter-clockwise (ccw) direction. The repositioning
mode in one direction only (cw or ccw) must be used whenever it is only allowed to move the tool in one
direction only.
Variable names
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Positioning mode Lock to cam
0
Move to cam position via shortest route.
1 Move to cam position only in positive
direction (CW).
g_byLockToCamMode BYTE
2 Move to cam position only in negative
direction (CCW).
Possible settings: Code
Default Selection
Comment
Positioning mode Lock to cam
0
Move to cam position via shortest route.
1 Move to cam position only in positive
direction (CW).
C3630/
000
0 0 {1} 2
2 Move to cam position only in negative
direction (CCW).
