Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-47
Possible settings: Code
Default Selection
Comment
C3715/
000
- - {0.0001
[m_units]}
- Display code: Material length which the cross cutter works to as a
start/stop length in the motion profile in the asynchronous motion
phase. The value is the difference between the start/stop length
and the synchronous X length.
Note: The value of this code is only recalculated during a
calculation sequence.
C3716/
000
- - {0.0001
[s_units]}
- Display code: Y position in the motion profile for the cutting length
at which the cross-cutter knife drum is located in the starting
position.
C3717/
000
- - {0.0001
[s_units]}
- Display code: Y position in the motion profile for the reject length
at which the cross-cutter knife drum is located in the starting
position.
C3718/
000
- - {0.0001
[s_units]}
- Display code: Y position in the motion profile for the test length at
which the cross-cutter knife drum is located in the starting
position.
C3719/
000
- - {0.0001
[s_units]}
- Display code: Y position in the motion profile for the start/stop
length at which the cross-cutter knife drum is located in the
starting position.
C3997/
000
- - {0.01} -
Display code: Template version
C3998/
000
- - {1} -
Display code: Display of current error (see Chapter 6.3)
C3999
1
2
3
- - {1} - Display code: Version release of the prepared solution
(subcode 1: project file, subcode 2: application library,
subcode 3: basic library):
The first and second numeral read from right-to-left define
the service pack.
The third and forth numeral read from right-to-left define
the sub version.
The fifth and sixth numeral read from right-to-left define
the main version.
Selection of control interface
0 Control via code
1 Control via CAN 1
2 Control via CAN 2
3 Control via CAN 3
4 Control via AIF 1
5 Control via AIF 2
C4000/
000
0 0 {1} 6
6 Control via AIF 3
