AT-S62 Web Browser Interface User’s Guide
Section VI: Port Security 295
Displaying MAC Address Security
To display the MAC address security level of a port, perform the
following procedure:
1. From the Home page, select Monitoring.
2. Select Network Security.
3. Select the Port Security tab.
4. Click the port whose port security level you want to view. A selected
port turns white. You can select more than one port at a time.
5. Click View.
The security information for the selected ports is displayed in the
Security for Port(s) page. An example is shown in Figure 107.
Figure 107 Security for Port(s) Tab
This page is for viewing purposes only. The columns in the page
are defined below:
Port
The number of the port.
Security Mode
The active security mode on the port.
Intruder Action
The column specifies the action taken by a port when it receives
an invalid frame.
❑ Discard: The port discards invalid frames. This is the default.
❑ Send Trap: The port discards invalid frames and sends a trap.
❑ Disable Port: The port discards invalid frames, sends a trap, and
disables the port.
