AT-S62 Web Browser Interface User’s Guide
Section IV: Spanning Tree Protocols 257
Table 11 lists the RSTP port costs with Auto-Detect when the port
is part of a port trunk.
3 - Point-to-Point
This parameter defines whether the port is functioning as a point-
to-point port. For an explanation of this parameter, refer to the
AT-S62 Menus Interface User’s Guide.
4 - Edge Port
This parameter defines whether the port is functioning as an edge
port. For an explanation of this parameter, refer to AT-S62 Menus
Interface User’s Guide.
6. After configuring the parameters, click Apply.
7. To permanently save the change, select the Save Config menu
selection.
100 Mbps 200,000
1000 Mbps 20,000
Table 11 RSTP Auto-Detect Port Trunk Costs
Port Speed Port Cost
10 Mbps 20,000
100 Mbps 20,000
1000 Mbps 2,000
Table 10 RSTP Auto-Detect Port Costs
Port Speed Port Cost
