AT-S62 Web Browser Interface User’s Guide
Section V: Virtual LANs 275
Modifying a Port-based or Tagged VLAN
This procedure explains how to add or remove ports from a port-based
or tagged VLAN. When modifying a VLAN, note the following:
❑ You cannot change the VID of a VLAN.
❑ You cannot change the name of a VLAN from a web browser
management session; you can from a local, Telnet, or SSH session.
❑ You cannot modify VLANs when the switch is operating in one of
the multiple VLAN modes.
To modify a VLAN, perform the following procedure:
1. From the Home Page, select Configuration.
2. Select the Layer 2 menu selection.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 101 on page 271.
4. Click the button next to the name of the VLAN you want to modify.
5. Click Modify.
The Modify VLAN window for the VLAN is displayed.
6. To add or remove ports from the VLAN, click on the appropriate ports
in the switch image.
Clicking on a port toggles it through the following possible
settings:
Untagged port
Tagged port
Port not a member of the VLAN
7. After making the necessary changes, click Apply.
Note
Untagged ports that are added to a VLAN are automatically
removed from their current untagged VLAN assignment. Untagged
ports that are removed from a VLAN are returned to the
Default_VLAN.
Removing an untagged port from the Default_VLAN without
assigning it to another VLAN will leave the port as an untagged
member of no VLAN.
