Chapter 10: File Downloads and Uploads
Section II: Advanced Operations 102
Note
The top portion of the tab returns the switch to its factory default
settings. For instructions, refer to Returning the AT-S62 Software to
the Factory Default Values on page 45.
4. In the TFTP Server IP Address field, enter the IP address of the network
node with the TFTP server software.
5. In the TFTP Operation field, click Upload.
6. In the TFTP Remote Filename field, enter a name for the file. This is the
name that the file will be stored as on the TFTP server.
7. In the TFTP Local Filename field, enter the name of the file in the
switch’s file system that you want to upload to the TFTP server.
Note
The TFTP File Type options are not used when uploading a file.
8. Click Apply.
The management software notifies you once the upload is
complete.
