Boonton 4500B RF Peak Power Analyzer
Getting Started 3-14
Table 3-3. Initialized Parameters
Parameter
Applies to: Default
Graph/Text/Help Mode Select Graph
Top Level Menu
Measurement Run
Measurement Mode Pulse
Parameters Related to the Chan # > Menu
Select CH 1
Channel CH1 On
CH2, CH Math Off
TRIG1, TRIG2 Off
MEM1, MEM2 Off
Vertical Scale (active marker)
Log Power All Channels 20 dB/Div
Linear Power All Channels 20 mW/Div
Log Volts All Channels 10 dBV/Div
Linear Volts All Channels 200mV/Div
Trig display TRIG1, TRIG2 0.5 V/Div
Vertical Center
Log All Channels 0.00 dB
Linear All Channels 0.00 dBm
Trig display TRIG1, TRIG2 0 Volts
Extensions (Menu)
Units CH1, CH2, CH Math dBm
MEM1, MEM2 dBm
TRIG1, TRIG2 Volts
dB Offset CH1, CH2 0.00 dB
Freq CF CH1, CH2 (if no sensor, 0.00 dB)
Peak Hold (Pulse, Modulated) All Channels Off
Define Pulse
Distal All Except CH Math 90%
Mesial All Except CH Math 50%
Proximal All Except CH Math 10%
Pulse Units All Except CH Math Volts
Video Bandwidth /Bandwidth CH1, CH2/TRIG1, TRIG2 High
Averaging CH1, CH2, TRIG1, TRIG2 8
Filter CH1, CH2, TRIG1, TRIG2 Auto
Range TRIG1, TRIG2 +/-50V
Impedance TRIG1, TRIG2 1M Ohms
