Boonton 4500B Peak Power Meter - Manual (Page 357)

Boonton 4500B RF Peak Power Analyzer
Maintenance 7-25
Table 7-15 (continued). Sensor Risetime
Sensor
Model(s)
Test Level
(dBm) Min
High BW
Measured Max Min
Low BW
Measured Max
57318
57340
20 ________
15ns 1us
________
10us
15 ________ ________
10 ________ ________
5 ________ ________
0 ________ ________
-5 ________ ________
57518
57540
20 ________
100ns 1us
________
10us
15 ________ ________
10 ________ ________
5 ________ ________
0 ________ ________
-5 ________ ________
58318
20 ________
10ns
15 ________
10 ________
5 ________
0 ________
-5 ________
59318
59340
20 ________
10ns 1us
________
10us
15 ________ ________
10 ________ ________
5 ________ ________
0 ________ ________
-5 ________ ________
For sensor models not listed, consult the sensor datasheet or Boonton Power Sensor Guide.
