PEL-2000 Programming Manual

96

Query Example

:PROG:MEM?
1

The memory number for
the current
program/sequence is
001.

:PROGram:SEQuence:SHORt:CHANnel

Program Number
Specific

Description

Simulates short circuits for load channels for the
current sequence number.

Syntax

:PROGram:SEQuence:SHORt:CHANnel

Parameter

(BIT WEIGHT)

Channel
number

(BIT WEIGHT)

Channel
number

1

1

16

5

2

2

32

6

4

3

64

7

8

4

128

8

Example

:PROG:SEQ:SHOR:CHAN
12

Simulates a short circuit
for channels 3 and 4.

Query Syntax

:PROGram:SEQuence:SHORt:CHANnel?

Return Parameter

(BIT WEIGHT)

Short
Channel
number

(BIT WEIGHT)

Short
Channel
number

1

1

16

5

2

2

32

6

4

3

64

7

8

4

128

8

Query Example

:PROG:SEQ:SHOR:CHAN?
12

Returns channels 3 and
4 are set as shorted for
the program sequence.
