COMMAND DETAILS
109
Query Example :RES:STAT:HIGH:RISE?
MIN
0.8000 For high range CR mode,
the minimum value for
the rising slew rate is 0.8
A/uS for the specific
channel.
:RESistance:DYNamic:LOW:L1/L2
Channel Specific
Command
Description Sets the low range resistance levels (Level 1 & 2)
for CR dynamic mode.
Syntax :RESistance:DYNamic:LOW:L1/L2 [OHM]
Parameter NRf+[OHM] Ohms
L1 10 Sets L1 to 10 ohms. (low
range only)
L2 20OHM Sets L2 to 20 ohms. (low
range only)
L1/L2 MIN Sets L1 or L2 to the
minimum level for the
specific channel.
L1/L2 MAX Sets L1 or L2 to the
maximum Level for the
specific channel.
Example :RES:DYN:LOW:L1 10 In low range CR
dynamic mode, Set L1
(level 1) to 10 ohms.
Query Syntax :RESistance:DYNamic:LOW:L1/L2? [MIN|MAX]
Return Parameter [MAX|MIN] Resistance
1 unit= 1 ohm Returns the resistance of
L1/L2.
Query Example :RES:DYN:LOW:L2? MAX
300 Returns the maximum
resistance allowed for
the channel. (PEL-2020)
