PEL-2000 Programming Manual
64
Return Parameter [MAX|MIN] Slew rate
1 Unit=1 amp/uS Returns the slew rate.
MAX/MIN Returns the allowable
maximum or minimum.
Query Example :CURR:DYN:FALL? MIN
0.0003 Shows the minimum
allowable value for the
falling slew rate as 0.0003
A/uS for the specific
channel and range.
:CURRent:DYNamic:T1/T2
Channel Specific
Command
Description Sets the timers T1 or T2 for CC dynamic mode for
the specific channel and range.
Syntax :CURRent:DYNamic:T1/T2 [S|ms]
Parameter [S] Time
T1/T2 0.1S Sets the T1/T2 time to 0.1
seconds.
T1/T2 1 Sets T1/T2 to 1 second.
T1/T2 MIN Sets the T1/T2 to the
minimum value.
T1/T2 MAX Sets the T1/T2 time to the
maximum time
Example :CURR:DYNA:T1 .1S Sets the T1 time to 100
milliseconds for the
specific channel.
Query Syntax : CURRent:DYNamic:T1/T2? [MIN|MAX]
Return Parameter [MAX|MIN] Time
1 Unit=1 second Returns T1/T2 time.
MAX/MIN Returns the allowable
maximum and minimum.
