PEL-2000 Programming Manual

44

:CONFigure:PROTection:CURRent:LEVel

Channel Specific
Command

Description

Sets the current protection level for the
current/specific channel. The level can be set to
any applicable level or to the channel
maximum/minimum.

Syntax

:CONFigure:PROTection:CURRent:LEVel
[A]|MIN|MAX

Parameter

Current Protection Level

.3

300mA

0.3A

300mA

300MA

300mA

MIN

Sets to the minimum level

MAX

Sets the current limit to
the maximum level

Example

:CONF:PROT:CURR:LEV
MAX

Sets the current limit to
20.40A (PEL2020)

Query Syntax

: CONFigure:PROTection:CURRent:LEVel? [MIN|MAX]

Return Parameter 1 unit = 1 amp

Current protection level

1

1 amp.

MAX/MIN

Returns the allowable
maximum and minimum.

Query Example

:CONF:PROT:CURR:LEV?

0.30

Current protection level
is at 300mA.
