PEL-2000 Programming Manual
106
BVALue 20 Sets B Value to 20 ohms.
(Low Range only)
AVALue MIN Sets A Value to the
minimum level for the
specific channel.
AVALue MAX Sets A Value to the
maximum level for the
specific channel.
Example :RES:STAT:LOW:BVAL 10 Sets low range CR static
mode B Value to 10
ohms.
Query Syntax :RESistance:STATic:LOW:AVALue/BVALue?
Return Parameter [MAX|MIN] Resistance
1 unit = 1 ohm Returns the resistance of
the A or B Value.
Query Example :RES:STAT:LOW:AVAL?
MAX
300 Returns the maximum
resistance allowed for
the channel. (PEL-2020)
:RESistance:STATic:LOW:RISE/FALL
Channel Specific
Command
Description Sets the low range rising/falling slew rate.
Syntax :RESistance:STATic:LOW:RISE/FALL [A/uS]
Parameter [A/uS] Slew rate
RISE/FALL 0.8A/uS Sets the rising/falling slew
rate to 0.8A/uS
RISE/FALL .8 Sets the rising/falling slew
rate to 0.8 A/uS
RISE/FALL MIN Sets to the slowest
rising/falling slew rate.
RISE/FALL MAX Sets to the fastest
rising/falling slew rate.
