COMMAND DETAILS
139
Query Syntax :POW:LOW:CURRent? [MAX|MIN]
Return Parameter [MAX|MIN] Current
1 unit = 1 amp Returns the current limit.
MAX/MIN Returns the allowable
maximum and minimum.
Query Example :POW:LOW:CURR?
7.0 Returns the current limit
for the specific channel.
:POWer:HIGH:AVALue/BVALue
Channel Specific
Command
Description Sets the high range A/B Value for constant power
mode.
Syntax :POWer:HIGH:AVALue/BVALue [W]
Parameter NRf+[W]
AVALue 1 Sets A Value to 1 watt.
BVALue 1W Sets B Value to 1 watt.
AVALue MIN Sets A Value to the
minimum level for the
specific channel.
AVALue MAX Sets A Value to the
maximum Level for the
specific channel.
Example :POWer:HIGH:AVAL 1 Sets A Value to 1 watt
for the high range.
Query Syntax :POWer:LOW:AVALue/BVALue? [MAX|MIN]
Return Parameter [MAX|MIN] Current
1 unit = 1 watt Returns the power of the A
or B Value.
MAX/MIN Returns the allowable
maximum and minimum.
