COMMAND DETAILS

57

Query Example

:CURR:STAT:REC?
0

A Value is active.

:CURRent:STATic:L1/L2

Channel Specific
Command

Description

Sets the A/B Value for constant current static
mode, where L1 is A Value and L2 is B Value. The
command is range dependant. If the current range
is Low, then the command will only apply to the
low range settings.

Syntax

:CURRent:STATic:L1|L2 [A]

Parameter

[A]

L1 1

Sets A Value to 1 Amp.

L2 2

Sets B Value to 2 Amps.

L1 1A

Sets A Value to 1 Amp.
(single channel only)

L1 MIN

Sets A Value to the
minimum level for the
specific channel.

L1 MAX

Sets A Value to the
maximum Level for the
specific channel.

Example

:CURR:STAT:L1 1

Sets A Value to 1 amp
for the current range

Query Syntax

:CURRent:STATic:L1?/L2? [MAX|MIN]

Return Parameter [MAX|MIN]

Current

1 unit = 1 amp

Returns the current of the
A Value (L1) or B Value
(L2).

MAX/MIN

Returns the allowable
maximum and minimum.

Query Example

:CURR:STAT:L2? MAX
10.2

Returns the maximum
current allowed for the
channel. (PEL-2020)
