PEL-2000 Programming Manual
138
AVALue MAX Sets A Value to the
maximum Level for the
specific channel.
Example :POWer:LOW:AVAL 1 Sets A Value to 1 watt
for the low range.
Query Syntax :POWer:LOW:AVALue/BVALue? [MAX|MIN]
Return Parameter [MAX|MIN] Current
1 unit = 1 watt Returns the power of the A
or B Value.
MAX/MIN Returns the allowable
maximum and minimum.
Query Example :POWer:LOW:BVAL? MAX
2 Returns the maximum
power allowed for the
channel/range.
:POWer:LOW:CURRent
Channel Specific
Command
Description Sets the current limit for constant power mode for
the low range only.
Syntax :POWer:LOW:CURRent [A]
Parameter [A]
1 Sets the current limit to
1A.
1A Sets the current limit to
1A.
MIN Sets the current limit to
the minimum level for the
specific channel.
MAX Sets the current limit to
the maximum level for the
specific channel.
Example :POW:CURR 1 Sets the current limit to
1A.
