COMMAND DETAILS

27

*ESE

Status Command

Description

The Standard Event Status Enable command
determines which events in the Standard Event
Status Event register can set the Event Summary
Bit (ESB) of the Status Byte register. Any bit
positions set to 1 enable the corresponding event.
Any enabled events set bit 5 (ESB) of the Status
Byte register. See page169.

Syntax

*ESE

Parameter

Bit(s) Set

Bit(s) Set

4

QYE

32

CME

8

DDE

64

~

16

EXE

128

~

Example

*ESE 40

Sets CME and DDE events
in the Standard Event
Status Event Register.

Query Syntax

*ESE?

Return Parameter

Bit(s) Set

Bit(s) Set

4

QYE

32

CME

QYE

8

DDE

64

~

16

EXE

128

~

Example

*ESE?
40

Returns the settings in the
Standard Event Status
Enable Register. Here CME
and QYE are enabled.

*ESR?

Status Command

Description

Reads the Standard Event Status Register. This
command also clears the Standard Event Status
Register. Page168.

Query Syntax

*ESR?
