437
Appendix
I/O Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
126 Network attribute 7 7D007D0H 0H ~
FFFFFFFFH
Ethernet TCP/IP message communication attribute
Bits 0 to 15:
Min timeout value (msec)
Bits 16 to 31: Mout timeout value (msec)
127 Network attribute 8 5050214H 0H ~
FFFFFFFFH
Ethernet TCP/IP message communication attribute
Bits 0 to 7:
CONNECT_TIMEOUT
(Change is prohibited)
(Setting of “0” is prohibited) (sec)
Bits 8 to 15: Connection retry interval
(IAI protocol B/TCP) (sec)
Bits 16 to 23: Send timeout value (sec)
Bits 24 to 31: IAI protocol B-SIO non-communication
check timer setting (sec)
(IAI protocol B/TCP connection trigger)
128 Network attribute 9 10000H 0H ~
FFFFFFFFH
Ethernet TCP/IP message communication attribute
Bits 0 to 15:
SEL server open timeout value (sec)
(No timeout check when “0” is set)
Bits 16 to 23: Connection retry interval
(Tracking vision system I/F) (sec)
129 Network attribute 10 0H 0H ~
FFFFFFFFH
Ethernet operation requirement
Bits 0 to 3:
Modbus/TCP (Remote I/O)
(0: Not in use
1: Use (Disable exception status)
2: Use (Enable exception status (upper
two digits of error number)))
* Refer to the explanation of error
levels in the operation manual and
perform processing appropriate for
each error level.
Bits 4 to 7: TCP/IP message communication
(0: Not in use, 1: Use)
Bits 8 to 31: Reserved (Operation requirement)
130 Own MAC address (H) 0H Reference
only (HEX)
Only the lower two bytes are valid.
131 Own MAC address (L) 0H Reference
only (HEX)
132 Own IP address (H) 192 1 ~ 255 * Setting of “0” and “127” is prohibited.
133 Own IP address (MH) 168 0 ~ 255
134 Own IP address (ML) 0 0 ~ 255
135 Own IP address (L) 1 1 ~ 254 * Setting of “0” and “255” is prohibited.
136 Subnet mask (H) 255 0 ~ 255
137 Subnet mask (MH) 255 0 ~ 255
138 Subnet mask (ML) 255 0 ~ 255
139 Subnet mask (L) 0 0 ~ 255
140 Default gateway (H) 0 0 ~ 255
141 Default gateway (MH) 0 0 ~ 255
142 Default gateway (ML) 0 0 ~ 255
143 Default gateway (L) 0 0 ~ 255
