113
Part 3 Controller Data Structure
Chapter 2 X-SEL Language Data
1. Values and Symbols Used in SEL Language
1.1 List of Values and Symbols Used
The functions required in a program are represented by values and symbols.
Function Global range Local range Remarks
Input port 000 ~ 299 (300)
Varies depending on
the function.
Output port 300 ~ 599 (300)
Varies depending on
the function.
Flag 600 ~ 899 (300) 900 ~ 999 (100)
Variable (integer)
200 ~ 299 (100)
1200 ~ 1299 (100)
1 ~ 99 (99)
1001 ~ 1099 (99)
99 is used for IN, INB,
OUT, OUTB, etc.
Variable (real)
300 ~ 399 (100)
1300 ~ 1399 (100)
100 ~ 199 (100)
1100 ~ 1199 (100)
199 is used for PPUT,
PGET, PARG, etc.
String 300 ~ 999 (700) 1 ~ 299 (299)
Tag number 1 ~ 256 (256)
Subroutine number 1 ~ 99 (99)
Load coordinate system 0 ~ 31 (32) SCARA axis only
Tool coordinate system 0 ~ 127 (128) SCARA axis only
Simple interference check zone number 1 ~ 10 (10) SCARA axis only
Zone number 1 ~ 4 (4)
Linear movement axis
only
Pallet number 1 ~ 10 (10)
Axis number 1 ~ 6 (6)
Varies depending on
the function.
Axis pattern 0 ~ 111111
Controller with increased memory
size (with gateway function)
1 ~ 20000 (20000)
Position
number
Controller without increased
memory size
1 ~ 4000 (40000)
Controller with increased memory
size (with gateway function)
1 ~ 128 (128)
Program
number
Controller without increased
memory size
1 ~ 64 (64)
Controller with increased memory
size (with gateway function)
1 ~ 9999 (9999)
Step
number
Controller without increased
memory size
1 ~ 6000 (6000)
Task level NORMAL/HIGH (2)
SIO channel number 1 ~ 2 (2)
Wait timer 1
1-shot pulse timer
16 (Number of timers
that can be operated
simultaneously)
Ladder timer Local flag (100)
Virtual input port (SEL system o SEL user
program)
7000 ~ 7299 (300)
Virtual output port (SEL user program o SEL
system)
7300 ~ 7599 (300)
Number of symbol definitions 1000
Number of times symbol can be used in
commands
5000 (including literals)
Used in common from
any program. Referenced separately in each program.
Cleared when the program is started.
Caution
x Variables 99 and 199 are special variables this system uses in operations. Avoid
using these two variables for general purposes.
x The values in the table represent ranges that can be processed by software. Items
that require physical devices, such as I/O ports and functions relating to axis number
and SIO, will be determined by possible combinations and models of commercial
boards, etc., available for each device application.
