430
Appendix
I/O Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
30 Input function selection
000
1 0 ~ 5 0: General-purpose input
1: Program start signal (ON edge) (Input ports 007 to
013: BCD-specified program number)
2: Program start signal (ON edge) (Input ports 007 to
013: Binary-specified program number)
3: Program start signal (ON edge)
(Input port Nos. 008 to 014: BCD specified program
number)
(Main application version 0.36 or later)
Note: The function of “I/O parameter No. 44: Input
function selection 014” (drive-source cutoff reset
related) is assigned to “I/O parameter No. 37:
Input function selection 007,” while the function
of “I/O parameter No. 43: Input function selection
013” (error reset, program start specified
program number) is assigned to “I/O parameter
No. 44: Input function selection 014.” To specify
a program number in 7 bits, all of the functions
from “I/O parameter No. 38: Input function
selection 008” to “I/O parameter No. 44: Input
function selection 014” must be set to “1:
Program start specified program number.”
4: Program start signal (ON edge)
(Input port Nos. 008 to 014: Binary specified program
number) (Main application version 0.36 or later)
Note: he function of “I/O parameter No. 44: Input
function selection 014” (drive-source cutoff reset
related) is assigned to “I/O parameter No. 37:
Input function selection 007,” while the function
of “I/O parameter No. 43: Input function selection
013” (error reset, program start specified
program number) is assigned to “I/O parameter
No. 44: Input function selection 014.” To specify
a program number in 7 bits, all of the functions
from “I/O parameter No. 38: Input function
selection 008” to “I/O parameter No. 44: Input
function selection 014” must be set to “1:
Program start specified program number.”
* If this parameter is used as a program start signal,
turn ON the signal for at least 100 msec so that the
program will start without fail.
* In the case of a controller with increased memory
size (with gateway), only program Nos. 1 to 79 can
be started via BCD specification, while only
program Nos. 1 to 127 can be started via binary
specification. Program No. 128 cannot be started
using this signal.
31 Input function selection
001
0 0 ~ 5 0: General-purpose input
1: Software reset signal (restart) signal (1 second ON)
* If continued operation is specified as the action
upon emergency stop, enable the software reset
signal (to provide a means of canceling the
operation).
32 Input function selection
002
0 0 ~ 5 0: General-purpose input
1: Servo ON
* ON edge: Equivalent to the all-valid-axis servo ON
command, OFF edge: Equivalent to the all-valid-
axis servo OFF command (A minimum interval of
1.5 seconds is required) (Must be executed in non-
operating condition)
33 Input function selection
003
1 0 ~ 5 0: General-purpose input
1: General-purpose input (Start the auto-start program
upon power-ON reset/software reset in the AUTO
mode)
2: Auto-start program start signal (ON edge: Start, OFF
edge: Abort all operations/programs (excluding the
I/O processing program at operation/program abort))
* If this parameter is used as an auto-start program
start signal, turn ON the signal for at least 100
msec so that the program will start without fail.
