83
Part 1 Installation
3.4 Multipoint I/O Board Connection Cables
Cable 1 Cable 2
Category Pin No. Color Port No. Function Category Pin No. Color Port No. Function
- 1 Brown-1 -
24-VDC for external power
supply
Pin Nos. 2 to 25/51 to 74
51 Brown-1 300 Alarm output
2 Red-1 000 Program start 52 Red-1 301 Ready output
3 Orange-1 001 General-purpose input 53 Orange-1 302 Emergency-stop output
4 Yellow-1 002 General-purpose input 54 Yellow-1 303 General-purpose input
5 Green-1 003 General-purpose input 55 Green-1 304 General-purpose input
6 Blue-1 004 General-purpose input 56 Blue-1 305 General-purpose input
7 Purple-1 005 General-purpose input 57 Purple-1 306 General-purpose input
8 Grey-1 006 General-purpose input 58 Grey-1 307 General-purpose input
9 White-1 007 Program specification (PRG No. 1) 59 White-1 308 General-purpose input
10 Black-1 008 Program specification (PRG No. 2) 60 Black-1 309 General-purpose input
11 Brown-2 009 Program specification (PRG No. 4) 61 Brown-2 310 General-purpose input
12 Red-2 010 Program specification (PRG No. 8) 62 Red-2 311 General-purpose input
13 Orange-2 011 Program specification (PRG No. 10) 63 Orange-2 312 General-purpose input
14 Yellow-2 012 Program specification (PRG No. 20) 64 Yellow-2 313 General-purpose input
15 Green-2 013 Program specification (PRG No. 40) 65 Green-2 314 General-purpose input
16 Blue-2 014 General-purpose input 66 Blue-2 315 General-purpose input
17 Purple-2 015 General-purpose input 67 Purple-2 316 General-purpose input
18 Grey-2 016 General-purpose input 68 Grey-2 317 General-purpose input
19 White-2 017 General-purpose input 69 White-2 318 General-purpose input
20 Black-2 018 General-purpose input 70 Black-2 319 General-purpose input
21 Brown-3 019 General-purpose input 71 Brown-3 320 General-purpose input
22 Red-3 020 General-purpose input 72 Red-3 321 General-purpose input
23 Orange-3 021 General-purpose input 73 Orange-3 322 General-purpose input
24 Yellow-3 022 General-purpose input
Input
74 Yellow-3 323 General-purpose input
Input
25 Green-3 023 General-purpose input - 75 Green-3 -
0-V for external power supply
Pin Nos. 2 to 25/51 to 74
- 26 Blue-3 -
24-VDC for external power
supply
Pin Nos. 27 to 50/76 to 99
76 Blue-3 324 General-purpose input
27 Purple-3 024 General-purpose input 77 Purple-3 325 General-purpose input
28 Grey-3 025 General-purpose input 78 Grey-3 326 General-purpose input
29 White-3 026 General-purpose input 79 White-3 327 General-purpose input
30 Black-3 027 General-purpose input 80 Black-3 328 General-purpose input
31 Brown-4 028 General-purpose input 81 Brown-4 329 General-purpose input
32 Red-4 029 General-purpose input 82 Red-4 330 General-purpose input
33 Orange-4 030 General-purpose input 83 Orange-4 331 General-purpose input
34 Yellow-4 031 General-purpose input 84 Yellow-4 332 General-purpose input
35 Green-4 032 General-purpose input 85 Green-4 333 General-purpose input
36 Blue-4 033 General-purpose input 86 Blue-4 334 General-purpose input
37 Purple-4 034 General-purpose input 87 Purple-4 335 General-purpose input
38 Grey-4 035 General-purpose input 88 Grey-4 336 General-purpose input
39 White-4 036 General-purpose input 89 White-4 337 General-purpose input
40 Black-4 037 General-purpose input 90 Black-4 338 General-purpose input
41 Brown-5 038 General-purpose input 91 Brown-5 339 General-purpose input
42 Red-5 039 General-purpose input 92 Red-5 340 General-purpose input
43 Orange-5 040 General-purpose input 93 Orange-5 341 General-purpose input
44 Yellow-5 041 General-purpose input 94 Yellow-5 342 General-purpose input
45 Green-5 042 General-purpose input 95 Green-5 343 General-purpose input
46 Blue-5 043 General-purpose input 96 Blue-5 344 General-purpose input
47 Purple-5 044 General-purpose input 97 Purple-5 345 General-purpose input
48 Grey-5 045 General-purpose input 98 Grey-5 346 General-purpose input
49 White-5 046 General-purpose input
Output
99 White-5 347 General-purpose input
Output
50 Black-5 047 General-purpose input - 100 Black-5 -
0-V for external power supply
Pin Nos. 27 to 50/76 to 99
