436
Appendix
I/O Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
123 Network attribute 4 0H 0H ~
FFFFFFFFH
Bits 0 to 3: Ethernet TCP/IP message
communication
IP address of connection destination on
server
Whether to permit 0.0.0.0 (IP address
of connection destination can be
ignored)
(0: Do not permit
1: Permit (not recommended))
* Note: Number of clients that can be
connected simultaneously to one
server port channel = 1
124 Network attribute 5 0H 0H ~
FFFFFFFFH
Ethernet TCP/IP message communication attribute
Ethernet client/server type
(0: Not in use
( 1: Client (Automatic assignment of own port
number)
(2: Client (Specification of own port number)
o This setting is not recommended because
of device limitations, such as an error
generation when the port is opened for
approx. 10 minutes after disablement of
close response check due to a power
failure at the connection destination, etc.)
3: Server (Specification of own port number))
* Note: Number of clients that can be connected
simultaneously to one server port channel = 1
Bits 0 to 3: IAI protocol B/TCP (MANU mode)
* PC software can be connected only in the
case of a client.
Bits 4 to 7: IAI protocol B/TCP (AUTO mode)
* PC software can be connected only in the
case of a client.
Bits 8 to 11: Channel 31 opened to user
Bits 12 to 15: Channel 32 opened to user
Bits 16 to 19: Channel 33 opened to user
Bits 20 to 23: Channel 34 opened to user
* If the parameter settings for own port number,
client/server type, IP address of connection
destination and port number of connection
destination do not match completely in the IAI
protocol B/TCP MANU or AUTO mode, the
connection will be cut off when the MANU/AUTO
mode is switched.
125 Network attribute 6 31E32H 0H ~
FFFFFFFFH
Bits 0 to 7: Module-initialization check timer
setting when Ethernet is used (100
msec)
Bits 8 to 15: Module-initialization check timer
setting when Ethernet is not used
(100 msec)
Bits 16 to 23: Increment of "PC/TP reconnection
delay time upon software reset"
when Ethernet is used (sec)
PC: PC software
TP: Teaching pendant
