TMP92CZ26A
92CZ26A-79
Symbol Name
Address
7 6 5 4 3 2 1 0
INTTB01 (TMRB0)
INTTB00 (TMRB0)
ITB01C ITB01M2 ITB01M1 ITB01M0 ITB00C ITB00M2 ITB00M1 ITB00M0
R R/W R R/W
INTETB0
INTTB00 &
INTTB01
enable
D8H
0 0 0 0 0 0 0 0
INTTB11 (TMRB1)
INTTB10 (TMRB1)
ITB11C ITB11M2 ITB11M1 ITB11M0 ITB10C ITB10M2 ITB10M1 ITB10M0
R R/W R R/W
INTETB1
INTTB10 &
INTTB11
enable
D9H
0 0 0 0 0 0 0 0
INTTX0 INTRX0
ITX0C
ITX0M2
ITX0M1
ITX0M0
IRX0C
IRX0M2 IRX0M1 IRX0M0
R R/W R R/W
INTES0
INTRX0 &
INTTX0
enable
DBH
0 0 0 0 0 0 0 0
INTADM INTSBI
IADM0C IADMM2 IADMM1 IADMM0 ISBI0C
ISBIM2 ISBIM1
ISBIM0
R R/W R R/W
INTESBIADM
INTSBI &
INTADM
enable
E0H
0 0 0 0 0 0 0 0
INTSPITX INTSPIRX
ISPITC ISPITM2 ISPITM1 ISPITM0 ISPIRC ISPIRM2
ISPIRM1 ISPIRM0
R R/W R R/W
INTESPI
INTSPI
enable
E1H
0 0 0 0 0 0 0 0
− INTUSB
−
−
−
−
IUSBC
IUSBM2 IUSBM1 IUSBM0
R
R/W
INTEUSB
INTUSB
enable
E3H
Always write “0”.
0 0 0 0
− INTALM
−
−
−
−
IALMC
IALMM2 IALMM1 IALMM0
R
R/W
INTEALM
INTALM
enable
E5H
Always write “0”.
0 0 0 0
− INTRTC
−
−
−
−
IRC IRM2 IRM1 IRM0
R
R/W
INTERTC
INTRTC
enable
E8H
Always write “0”.
0 0 0 0
− INTKEY
−
−
−
− IKC
IKM2
IKM1
IKM0
R
R/W
INTEKEY
INTKEY
enable
E9H
Always write “0”.
0 0 0 0
lxxM2
lxxM1
lxxM0
Function (Write)
0 0 0
Disables
interrupt
requests
0
0
1
Sets interrupt priority level to 1
0
1
0
Sets interrupt priority level to 2
0
1
1
Sets interrupt priority level to 3
1
0
0
Sets interrupt priority level to 4
1
0
1
Sets interrupt priority level to 5
1
1
0
Sets interrupt priority level to 6
1 1 1
Disables
interrupt
requests
Interrupt request flag
