TMP92CZ26A
92CZ26A-577
(2) Minute column register (for PAGE0/1)
7 6 5 4 3 2 1 0
Bit symbol MI6 MI5 MI4 MI3 MI2 MI1 MI0 MINR
(1321H)
Read/Write R/W
After reset Undefined
Function "0" is read. 40 min,
column 20 min,
column 10 min,
column 8 min,
column
4 min,
column
2 min,
column
1 min,
column
0 0 0 0 0 0 0 0 min
0 0 0 0 0 0 1 1 min
0 0 0 0 0 1 0 2 min
0 0 0 0 0 1 1 3 min
0 0 0 0 1 0 0 4 min
0 0 0 0 1 0 1 5 min
0 0 0 0 1 1 0 6 min
0 0 0 0 1 1 1 7 min
0 0 0 1 0 0 0 8 min
0 0 0 1 0 0 1 9 min
0 0 1 0 0 0 0 10 min
:
0 0 1 1 0 0 1 19 min
0 1 0 0 0 0 0 20 min
:
0 1 0 1 0 0 1 29 min
0 1 1 0 0 0 0 30 min
:
0 1 1 1 0 0 1 39 min
1 0 0 0 0 0 0 40 min
:
1 0 0 1 0 0 1 49 min
1 0 1 0 0 0 0 50 min
:
1 0 1 1 0 0 1 59 min
Note: Do not set the data other than showing above.
