TMP92CZ26A
92CZ26A-305
TMRB0 Flip-Flop Control Register
7 6 5 4 3 2 1 0
Bit symbol − −
TB0C1T1 TB0C0T1 TB0E1T1 TB0E0T1 TB0FF0C1 TB0FF0C0
Read/Write W* R/W W*
After Reset 1 1 0 0 0 0 1 1
TB0FF0 inversion trigger
0: Disable trigger
1: Enable trigger
Function
Always write “11”
*Always read as “11”.
When
capture
UC10 to
TB0CP1H/L
When
capture
UC10 to
TB0CP0H/L
When UC10
matches
with
TB0RG1H/L
When UC10
matches
with
TB0RG0H/L
Control TB0FF0
00: Invert
01: Set
10: Clear
11: Undefined
*Always read as “11”.
Timer flip-flop control(TB0FF0)
00 Invert
01 Set to “11”
10 Clear to “00”
11 Undefined (Always read as “11”)
Figure 3.13.6 Register for TMRB (4)
TB0FF0 control
Inverted when UC10 value matches the valued in TB0RG0H/L
0 Disable trigger
1 Enable trigger
TB0FF0 control
Inverted when UC10 value matches the valued in TB0RG1H/L
0 Disable trigger
1 Enable trigger
TB0FF0 control
Inverted when UC10 value is captured into TB0CP0H/L
0 Disable trigger
1 Enable trigger
TB0FF0 control
Inverted when UC10 value is captured into TB0CP1H/L
0 Disable trigger
1 Enable trigger
TB0FFCR
(1183H)
Prohibit
read-
modify-
write
