TMP92CZ26A
92CZ26A-7
Table 2.1.1 Pin number and the name
Ball
No.
Pin name
Ball
No.
Pin name
Ball
No.
Pin name
Ball
No.
Pin name
A1 Dummy1 D9 P73,EA24 J15 PT5,LD13 P15 PK4,LHSYNC
A2 PG2,AN2, MX D10 PF4,I2S1DO J16 P47,A7 P16 P13,D11
A3 PA6,KI6 D11 PF7,SDCLK J17 P46,A6 P17 P14,D12
A4 PA5,KI5 D12 PJ4,SDLUDQM K1 PN3,KO3 R1 X2
A5 PA3,KI3 D13 P85, CSZC K2 PN4,KO4 R2 PC7,KO8
A6 PA1,KI1 D15 PU6,LD22 K3 PN5,KO5 R3 PC3,INT3,TA2IN
A7 DVCC1A5 D16 P61,A17 K4 PN6,KO6 R4 PX5,X1USB
A8 PF1,I2S0DO D17 P60,A16 K6 DVCC3A2 R5 PP7,TB1OUT0
A9 PJ6,NDCLE E1 P96,PX,INT4 K12 DVCC3A7 R6 PP1,TA3OUT
A10 PJ1, SDCAS , SRLUB E2 PW1 K14 PT4,LD12 R7 PP3,INT5,TA7OUT
A11 P87, CSXB , CE 1 ND E3 PW2 K15 PT3,LD11 R8 PP5,INT7,TB1IN0
A12 P83, 3 CS , CSXA E4 PW3 K16 P45,A5 R9 PR2, SPCS
A13 P81, 1 CS , SDCS E14 PU7,LD23,EO_TRGOUT K17 P44,A4 R10 PX7
A14 P72, WRLU ,NDWE E15 PU4,LD20 L1 PK2,LFR R11 PZ0,EI_PODDATA
A15 P70, RD E16 P57,A15 L2 PN7,KO7 R12 PZ2,EI_PODREQ
A16 P65,A21 E17 P56,A14 L3 PM1,MLDALM,TA1OUT R13 PZ4,EI_TRGIN
A17 Dummy3 F1 DVCC1B1 L4 PM7,PWE R14 PZ6,EO_MCUDATA
B1 VREFH F2 PW6 L6 DVSS3 R15 PZ7,EO_MCUREQ
B2 PG5,AN5 F3 PW5 L12 DVSS7 R16 P15,D13
B3 PG3,AN3,MY, ADTRG F4 PW4 L14 PT2,LD10 R17 DVCC1A3
B4 PA7,KI7 F6 DVCC3A12 L15 PT1,LD9 T1 X1
B5 PA2,KI2 F7 DVCC3A11 L16 P43,A3 T2 AM0
B6 PA0,KI0 F8 DVSS11 L17 P42,A2 T3 AM1
B7 PF2,I2S0WS F9 DVCC3A10 M1 PK3,LVSYNC T4 PP6,TB0OUT0
B8 PF0,I2S0CKO F10 DVSS10 M2 PC0,INT0 T5 PL0,LD0
B9 PJ5,NDALE F11 DVCC3A9 M3 PM2, ALARM , MLDALM T6 PL2,LD2
B10 PJ2, SDWE , SRWR F14 PU5,LD21 M4 P90,TXD0 T7 PL4,LD4
B11 PJ0, SDRAS , SRLLB F15 PU2,LD18 M6 DVCC3A3 T8 PL5,LD5
B12 P86. CSZD , CE 0 ND F16 P55,A13 M7 DVSS4 T9 PR1,SPDO
B13 P82, 2 CS , CSZA
,
SDCS F17 P54,A12 M8 DVCC3A4 T10 PL6,LD6
B14 P75,R/ W ,NDR/ B G1 DVCC3B1 M9 DVSS5 T11 PK1,LLOAD
B15 P71, WRLL ,NDRE G2 PW7 M10 DVCC3A5 T12 P00,D0
B16 P64,A20 G3 PV0,SCLK0 M11 DVSS6 T13 P02,D2
B17 DVCC1A4 G4 PV1 M12 DVCC3A6 T14 P04,D4
C1 AVCC G6 DVSS1 M14 PK7,LGOE2 T15 P06,D6
C2 VREFL G7 DVSS12 M15 PT0,LD8 T16 P11,D9
C3 PG4,AN4 G12 DVSS9 M16 P41,A1 T17 P12,D10
C4 PG1,AN1 G14 PU3,LD19 M17 P40,A0 U1 Dummy2
C5 PA4,KI4 G15 PU0,LD16 N1 DVCC1A1 U2 RESET
C6 PC5,EA27 G16 P53,A11 N2 PC1,INT1,TA0IN U3 D+
C7 P76, WAIT G17 P52,A10 N3 P91,RXD0 U4 D-
C8 PF5,I2S1WS H1 PV7,SCL N4 DVSS1C U5 DVCC1A2
C9 PF3,I2S1CKO H2 PV6,SDA N14 PK6,LGOE1 U6 PL1,LD1
C10 PJ7,SDCKE H3 PV3 N15 PK5,LGOE0 U7 PL3,LD3
C11 PJ3,SDLLDQM H4 PV2 N16 P17,D15 U8 XT1
C12 P84, CSZB H6 DVCC3A1 N17 P16,D14 U9 XT2
C13 P80, 0 CS H12 DVCC3A8 P1 DVCC1C U10 PL7.LD7
C14 P67,A23 H14 PU1,LD17 P2 PC2,INT2 U11 PK0,LCP0
C15 P66,A22 H15 PT7,LD15 P3 P92,SCLK0, 0 CTS U12 P01,D1
C16 P63,A19 H16 P51,A9 P5 PX4,CLKOUT, LDIV U13 P03,D3
C17 P62,A18 H17 P50,A8 P6 PP2,TA5OUT U14 P05,D5
D1 P97,PY J1 PN2,KO2 P7 PP4,INT6,TB0IN0 U15 P07,D7
D2 AVSS J2 PN1,KO1 P8 PR0,SPDI U16 P10,D8
D3 PW0 J3 PN0,KO0 P9 PR3,SPCLK U17 Dummy4
D5 PG0,AN0 J4 PV4 P10 DBGE
D6 PC6,EA28 J6 DVSS2 P11 PZ1,EI_SYNCLK
D7 PC4,EA26 J12 DVSS8 P12 PZ3,EI_REFCLK
D8 P74,EA25 J14 PT6,LD14 P13 PZ5,EI_COMRESET
Note1: The P96, P97 and PG0~PG5 operate with the AVCC power supply.
Note2: The PW0~PW7 and PV0~PV7 operate with the DVCC3B power supply.
Note3: The X1 and X2 operate with the DVCC1C power supply.
