TMP92CZ26A
92CZ26A-282
TMRA5 Flip-Flop Control Register
7 6 5 4 3 2 1 0
Bit symbol TA5FFC1 TA5FFC0 TA5FFIE TA5FFIS
Read/Write R/W R/W
After reset 1 1 0 0
Function 00: Invert TA5FF
01: Set TA5FF
10: Clear TA5FF
11: Don’t care
TA5FF
control for
inversion
0: Disable
1: Enable
TA5FF
inversion
select
0: TMRA4
1: TMRA5
0 Inversion by TMRA4
TA5FFIS
1 Inversion by TMRA5
0 Disabled
TA5FFIE
1 Enabled
00 Inverts the value of TA5FF (Software inversion)
01 Sets TA5FF to “1”
10 Clears TA5FF to “0”
11 Don’t care
Note: The values of bits 4 to 6 of TA5FFCR are “1” when read.
Figure 3.12.14 Register for TMRA (10)
TA5FFCR
(1115H)
Read-
modify-
write
instructions
are
prohibited.
Control of TA5FF
Inversion signal for timer flip-flop 5 (TA5FF)
(Don’t care except in 8-bit timer mode)
Inversion of TA5FF
