TMP92CZ26A
92CZ26A-514
7 6 5 4 3 2 1 0
bit Symbol HSW7 HSW6 HSW5 HSW4 HSW3 HSW2 HSW1 HSW0
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function LHSYNC width (bits 7-0)
7 6 5 4 3 2 1 0
bit Symbol LDW7 LDW6 LDW5 LDW4 LDW3 LDW2 LDW1 LDW0
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function LLOAD width (bits 7-0)
7 6 5 4 3 2 1 0
bit Symbol O0W7 O0W6 O0W5 O0W4 O0W3 O0W2 O0W1 O0W0
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function LGOE0 width (bits 7-0)
7 6 5 4 3 2 1 0
bit Symbol O1W7 O1W6 O1W5 O1W4 O1W3 O1W2 O1W1 O1W0
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function LGOE1 width (bits 7-0)
7 6 5 4 3 2 1 0
bit Symbol O2W7 O2W6 O2W5 O2W4 O2W3 O2W2 O2W1 O2W0
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function LGOE2 width (bits 7-0)
7 6 5 4 3 2 1 0
bit Symbol O2W9 O2W8 O1W9 O1W8 O0W8 LDW9 LDW8 HSW8
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function
LGOE2 width (bits 9-8) LGOE1 width (bits 9-8) LGOE0
width (bit 8)
LLOAD width (bits 9-8) LHSYNC
width (bit 8)
LCDHSW
(0294H)
LCDLDW
(0295H)
LCDHO0W
(0296H)
LCDHO1W
(0297H)
LCDHO2W
(0298H)
LCDHWB8
(0299H)
