TMP92CZ26A
92CZ26A-730
(12) DMAC (7/7)
Symbol Name Address 7 6 5 4 3 2 1 0
DMAE5 DMAE4 DMAE3 DMAE2 DMAE1 DMAE0
R/W
0 0 0 0 0 0 HDMAE
DMA
enable
Register
097EH
DMA channel operation
0: Disable 1: Enable
DMATE DMATR6 DMATR5 DMATR4 DMATR3 DMATR2 DMATR1 DMATR0
R/W
0 0 0 0 0 0 0 0
HDMATR
DMA
timer
Register
097FH
Timer
operation
0: Disable
1: Enable
Maximum bus occupancy time setting
The value to be set in should be obtained by
“Maximum bus occupancy time / (256/f
SYS
)”.
“00H” cannot be set.
