TMP92CZ26A
92CZ26A-542
•
Memory Map Image and Data Output in Each Display Mode
STN monochrome (1-pixel display data = 1-bit memory data)
Display Memory
LD Bus Output
8-bit type
LD0 0
→ 8
LD1 1
→ 9
LD2 2
→ 10
LD3 3
→ 11
LD4 4
→ 12
LD5 5
→ 13
LD6 6
→ 14
LD7 7
→ 15
Note: When setting 240 segment, 256 segment size of data is required.
STN 4-grayscale (1-pixel display data = 2-bit memory data)
Display Memory
LD Bus Output
8-bit type
LD0
1 - 0
→ 17-16
LD1 3 - 2
→ 19-18
LD2 5 - 4
→ 21-20
LD3 7- 6
→ 23-22
LD4 9- 8
→ 25-24
LD5 11-10
→ 27-26
LD6 13-12
→ 29-28
LD7 15-14
→ 31-30
Figure 3.19.2 Memory Map Image and Data Output in STN Monochrome/4-Grayscale Mode
Address 0 Address 1 Address 2 Address 3
LSB MSB
D0 D31
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Address 0 Address 1 Address 2 Address 3
LSB MSB
D0 D31
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
