TMP92CZ26A
92CZ26A-277
TMRA23 Mode Register
7 6 5 4 3 2 1 0
Bit symbol TA23M1 TA23M0 PWM21 PWM20 TA3CLK1 TA3CLK0 TA2CLK1 TA2CLK0
Read/Write R/W
After reset 0 0 0 0 0 0 0 0
Function Operation mode
00: 8-bit timer mode
01: 16-bit timer mode
10: 8-bit PPG mode
11: 8-bit PWM mode
PWM cycle
00: Reserved
01: 2 6
10: 2 7
11: 2 8
TMRA3 clock for TMRA3
00: TA2TRG
01:
φT1
10: φT16
11:
φT256
TMRA2 clock for TMRA2
00: TA2IN pin
01:
φT1
10: φT4
11:
φT16
00 TA2IN (External input)
01
φT1
10
φT4
11
φT16
TA23MOD ≠01 TA23MOD =01
00 Comparator output
from TMRA2
01
φT1
10
φT16
11 φT256
Overflow output from TMRA2
(16-bit timer mode)
00 Reserved
01 2 6 × Clock source
10 2 7 × Clock source
11 2 8 × Clock source
00 8 timer
× 2ch
01 16-bit timer
10 8-bit PPG
11 8-bit PWM (TMRA2),
8-bit timer (TMRA3)
Figure 3.12.9 Register for TMRA (5)
TA23MOD
(110CH)
PWM cycle selection
TMRA3 input clock
TMRA23 operation mode selection
TMRA2 input clock
