TMP92CZ26A
92CZ26A-686
(1) I/O ports (9/11)
Symbol Name Address 7 6 5 4 3 2 1 0
P17D P16D P15D P14D P13D P12D P11D P10D
R/W
1 1 1 1 1 1 1 1
P1DR
PORT1
drive
register
0081H
Input/Output buffer drive register for standby mode
P27D P26D P25D P24D P23D P22D P21D P20D
R/W
1 1 1 1 1 1 1 1
P2DR
PORT2
drive
register
0082H
Input/Output buffer drive register for standby mode
P37D P36D P35D P34D P33D P32D P31D P30D
R/W
1 1 1 1 1 1 1 1
P3DR
PORT3
drive
register
0083H
Input/Output buffer drive register for standby mode
P47D P46D P45D P44D P43D P42D P41D P40D
R/W
1 1 1 1 1 1 1 1
P4DR
PORT4
drive
register
0084H
Input/Output buffer drive register for standby mode
P57D P56D P55D P54D P53D P52D P51D P50D
R/W
1 1 1 1 1 1 1 1
P5DR
PORT5
drive
register
0085H
Input/Output buffer drive register for standby mode
P67D P66D P65D P64D P63D P62D P61D P60D
R/W
1 1 1 1 1 1 1 1
P6DR
PORT6
drive
register
0086H
Input/Output buffer drive register for standby mode
P76D P75D P74D P73D P72D P71D P70D
R/W
1 1 1
1 1 1 1
P7DR
PORT7
drive
register
0087H
Input/Output buffer drive register for standby mode
P87D P86D P85D P84D P83D P82D P81D P80D
R/W
1 1 1 1 1 1 1 1
P8DR
PORT8
drive
register
0088H
Input/Output buffer drive register for standby mode
P97D P96D P92D P91D P90D
R/W R/W
1 1 1 1 1
P9DR
PORT9
drive
register
0089H
Input/Output buffer
drive register for
standby mode
Input/Output buffer drive register
for standby mode
PA7D PA6D PA5D PA4D PA3D PA2D PA1D PA0D
R/W
1 1 1 1 1 1 1 1
PADR
PORTA
drive
register
008AH
Input/Output buffer drive register for standby mode
PC7D PC6D PC5D PC4D PC3D PC2D PC1D PC0D
R/W
1 1 1 1 1 1 1 1
PCDR
PORTC
drive
register
008CH
Input/Output buffer drive register for standby mode
PF7D PF5D PF4D PF3D PF2D PF1D PF0D
R/W R/W
1 1 1 1 1 1 1
PFDR
PORTF
drive
register
008FH
Input/Output buffer drive register for standby mode
